VisionNav VNK 15
Platform AMR
VisionNav Robotics manufactures the VNK 15 as a Platform AMR. The published payload of the VNK 15 is 1,500 kg. VisionNav Robotics does not publish a navigation method for the VNK 15. MAG has not deployed the VNK 15.
What are the key figures?
- Payload
- 1,500 kg
- Top speed
- 1.8 m/s
- Lift height
- 60 mm
- Navigation
- Not published
- Minimum aisle
- Not published
What are the full specifications?
| Type | Platform AMR |
|---|---|
| Payload | 1,500 kg |
| Lift height | 60 mm |
| Top speed | 1.8 m/s |
| Turning radius | 1,200 mm |
| Environment | indoor |
| Jobs | Carry a load on the deck, Lift and move racks |
Built for high-load top-lift handling and large-scale fleet scheduling. VisionNav states stable continuous operation in ultra-low temperature conditions, which makes this the cold storage candidate in the range. VisionNav does not publish navigation method, overall footprint or battery specification for this model.
Specifications reflect a standard configuration and are subject to change by the manufacturer. Optional masts, attachments, batteries, and navigation modes can change rated capacity and performance. MAG confirms as-configured specifications during site assessment.
When were these specifications verified?
Specifications verified 1 October 2026.
Which machines are closest to the VNK 15?
How the VNK 15 is commissioned
The VNK 15 is matched to the plant, installed with the fleet, and supported after launch.
